Medical Equipment and Accessories
Autoclave cum shredder Sterilizer
SPECIFICATIONS
- Horizontal Cylindrical High Speed Steam Steriliser
- Chamber capacity - 150 to 200 litre
- Conforms to third party certification
- Fully automatic steam jacketed suitable for operation on electricity
- Working temperature range 121 degree C - 134 degree C
- Configurable working temperature and sterilisation cycle time
- Built-in electrically heated Steam Generator (made of SS 316 (AISI 316) with low water protection system), works with 3 phase 400/440 V 50 Hz AC supply
- Microprocessor Controlled, with preselected Sterilisation Programs
|
Provision of Lock on Steriliser Chamber door: |
Automatic Lock |
|
Type of Door: |
Hinged type |
|
Display facility for Sterilisation Cycle parameters |
Chamber Temperature,Cycle number,Batch Number,,Time and date,Alarm indicator,Low water indicator |
|
Print facility for record generation of dates, time, load, identification number and operating parameters (temperature and holding time etc): |
Yes, by an inbuilt printer unit |
|
Warranty Period |
3 year |
|
No of Doors in Steriliser |
1 |
|
Type of user friendly Interface (for microprocessor controlled Sterilizer) to specify parameters for running Sterilization cycle: |
Touch screen interface |
|
Data Transfer facility through USB /RS232 port to computer/laptop on real time basis |
Yes |
|
Air removal from Sterilisation chamber, after loading the steriliser, by on for more pressure/vacuums pulsing for proper steam penetration |
YES |
|
Integrated Shredder (for shredding the load in Sterilisation chamber) |
Yes, with Microprocessor controlled |
|
Material: Shredder parts; |
SS 316 or SS 316L |
|
Power of Motor used for Shredding |
Must be of >= 2 HP, >= 1000 RPM, 220 V, 50 HZ AC motor, and able to deal with shredding of bio medical waste land as per Steriliser capacity |
|
Number of Rails: |
2 |
|
Long Handle: |
1 |
|
Sterilisation Carriages |
1 |
|
Pull out Trays/Tanks |
0 |
|
Floor loading carts |
2 |
|
Transfer carriages: |
1 |
